Diesel Generator Specifications |
|
Manufacturer: |
Yangzhou Zhengchi Power Equipment Co.,Ltd. |
|
Model: |
ZCDL-C440 |
|
Prime Power: |
400KW / 500KVA |
|
Standby Power: |
440KW / 550KVA |
|
Frequency: |
50HZ |
|
Voltage: |
400/230V |
|
Phase: |
3 Phase |
|
P.F（COS￠）: |
0.8 |
|
Fuel: |
Diesel |
|
Rated Current: |
720A |
|
Start Method: |
24V DC Start Battery |
|
Accessory: |
Battery, wire, exhaust pipe, muffler, damper, breaker, tools |
|
Altitude: |
≤1000m |
|
Open Type Generator Size: |
3400（mm）×1380（mm）×2050（mm） |
|
Open Type Generator Weight: |
4290KG |
|
Silent Type Generator Size: |
4630（mm）×1660（mm）×2250（mm） |
|
Silent Type Generator Weight: |
5700KG |
|
|
|
|
|
|
|
|
|
|
|
Engine Specifications |
|
Manufacturer: |
Chongqing Cummins Engine Co., Ltd |
|
Model: |
KTA19-G3A |
|
Air Intake System: |
Turbo, Water/Air cooling |
|
Fuel System: |
PT type fuel pump |
|
Cylinder Arrangement: |
6 in line |
|
Displacement: |
19L |
|
Bore and Stroke: |
159×159 mm |
|
Compression Ratio: |
13.9:1 |
|
Rated RPM: |
1500rpm |
|
Maximum Output Power: |
504KW/675HP |
|
Governor Type: |
Electronic |
|
Exhaust System |
|
Exhaust Gas Flow: |
1604L/s |
|
Exhaust Temperature: |
557℃ |
|
Max Back Pressure: |
10kPa |
|
Air Intake System |
|
Max Intake Restriction: |
6.23kPa |
|
Burning Capacity: |
579L/s |
|
Air Flow: |
9800L/s |
|
Fuel System |
|
100%( Prime Power) Load: |
203 g/Kw.h |
|
75%(Prime Power) Load: |
207 g/Kw.h |
|
50%(Prime Power) Load: |
216 g/Kw.h |
|
100%( Prime Power) Load: |
101.9L/h |
|
Oil System |
|
Total Oil Capacity: |
50L |
|
Oil Consumption: |
≤4g/kwh |
|
Engine Oil Tank Capacity: |
38L |
|
Oil Pressure at Rated RPM: |
345-483kPa |
|
Cooling System |
|
Total Coolant Capacity: |
106L |
|
Thermostat: |
82-93℃ |
|
Max Water Temperature: |
104℃ |
|
|
|
|
|
|
|
|
|
|
|
Alternator Specifications |
|
Manufacturer: |
Mecc Alte Alternator (Haimen) Ltd |
|
Model: |
ECO40-3S/4 |
|
Rated Capacity: |
500KVA |
|
Winding: |
100% Copper Wire |
|
Frequency: |
50HZ |
|
Speed: |
1500 RPM |
|
Connecting Type: |
3 Phase and 4 Wires, “Y” type connecting |
|
Power Factor: |
0.8 |
|
Protection Grade: |
IP23 |
|
Exciter Type: |
Brushless, self-exciting, with AVR |
|
Insulation Class, Temperature Rise: |
H/H |
|
Alternator Warranty: |
2 Year No Time Limited |
|
Voltage Regulation: |
≥±5% |
|
|
|
|
|
|
|
|
|
|
|
Control System Specifications |
|
Manufacturer: |
DEEP SEA ELECTRONICS PLC (UK) |
|
Model: |
DSE8610 |
|
Type: |
Automatic Parallel Operation |
|
Operation: |
Automatic Start and Auto Mains (Utility) Failure Control |
|
Alarm Protect: |
Engine pre-heat, Current monitoring, Comprehensive
Shutdown, Charge Failure |
